Automatic Generator Transfer Switch 160A 400V - Power Load Isolation & Actuating Switch for Home Backup & Emergency Power Supply

Specification Item Type Generator Transfer Switch Material PC Voltage Rated Working Voltage: AC400V; Control Voltage: 220V; Rated Isolation Voltage Ui: 1000V; Rated Impulse Withstand Voltage Uimp: 8KV Current Rated Short Time Withstand Current: 9kA Usage Category AC 33B Rated Production Capacity 10Ie Rated Breaking Capacity 10Ie Rated Power 50, 60HZ Grade PC Working Temperature - 20 to 45 ℃ (24h average value shall not exceed 35 ℃) Operating Humidity The average humidity at 40 ℃ shall not exceed 50%, and no condensation is allowed. Package List 1 x Generator Transfer Switch; 1 x Handle; 2 x Key; 1 x Manual; 12 x Bolt; 12 x Nut Note 1. The left and right mounting brackets of the change over switch must be fixed on the same flat plane. The size of the mounting hole should be adjusted according to the actual situation. It is strictly prohibited to use the wrong size of the opening to forcibly install the switch, which will lead to the internal deformation of the switch, or even direct damage to the switch. 2. It is recommended to use busbar for the installation of switches 2000A. If the cable installation will increase

Multi The switch supports multiple functions, including short circuit, overload, phase loss and undervoltage , which is and

Advanced Technology Double row composite contacts, horizontal pull structure, micro motor advanced energy storage and microelectronic control technology are adopted to basically realize no arc crossing.

4 Functions This switch has 4 functions, emergency manual operation, electric remote control operation, emergency disconnection under automatic control, and automatic control

Applicable Scenarios The switch can be used in homes and public places, especially in office buildings and public places that need fire .

The load isolation actuating switch is equipped with a mechanical interlock device to ensure the of the main and standby power supplies without mutual interference.
